What is led controller?The Ultimate Guide
LED controller is a special chip processing control LED lights display function of the switch. The controller will control the driver circuit according to the program input in advance so that LED lights can be normal and change regularly as we think. The LED controller can adjust the RGB tricolor intelligent light, and also can be used for remote dimming. We can sourcing many kinds of led controller from China.
How many kinds of led controller?
Lightstec is one of the most professional LED controller suppliers in China. We have a various controller for led strip light.Including RGB controller, RGB+W controller, RGB+CCT led controller,dimmable controller,DMX512 controller. Welcome sourcing led controller from us!
Touch Panel CCT controller (COLOR BOX) LT-TP1-D
Connection:Common anode
Working voltage:12V - 24V
Output current:2*4A=8A
Output power:12V<96W,24V<192W
Touch Panel RGB controller (COLOR BOX) LT-TP1-RGB
Connection:Common anode
Working voltage:12V - 24V
Output current:3*4A=12A
Output power:12V<144W,24V<288W
Touch Panel RGBW controller (COLOR BOX) LT-TP3-RGBW
Connection:Common anode
Working voltage:12V - 24V
Output current:4*4A=16A
Output power:12V<192W,24V<384W
RF5 key touch RGB controller LT-RFT-05
Connection:Common anode
Working voltage:12V-24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
RF6 key iron shell RGB controller GT666 LT-RFT-06
Connection:Common anode
Working voltage:12V-24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
2.4G touch RGB controller LT-G-301
Connection:Common anode
Working voltage:12V-24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
RF20 key touch RGB controller (iron shell RJ45 signal cable)LT-RJ45-T1
Connection:Common anode
Working voltage:12V - 24V
Output current:3*10A=30A
Output power:12V<360W,24V<720W
RF20 key RGB controller LT-RFB-20K
Connection:Common anode
Working voltage:12V - 24V
Output current:3*4A=12A
Output power:12V<144W,24V<288W
RF24 key iron shell RGB controller(360W)LT-RFH-24K
Connection:Common anode
Working voltage:12V - 24V
Output current:3*10A=30A
Output power:12V<360W,24V<720W
Rain-proof AC sync RGB controller (720W)LT-RGB-1000AC
Connection:Common anode
Working voltage:12V-24V
Output current:6*10A=60A
Output power:12V<720W,24V<1440W
programmable Full color controller(with SD card) LT-T-4000-TTL
Connection:Common anode
Working voltage:110V/220V
IC:TM1803 TM1804 TM1809 TM1812 TM1903 1904 1909 1912
UCS: 1903 1909 1912
BS: 0815 0825 0901
TLS: 3001 3002 3008 6803
WS:2811 2801 2812
Output power:8192 IC PIXEL
programmable Full color controller (with SD card) LT-T-1000B
Connection:Common anode
Working voltage:5V-24V
IC:TM1803 TM1804 TM1809 TM1812 TM1903 1904 1909 1912
UCS: 1903 1909 1912
BS: 0815 0825 0901
TLS: 3001 3002 3008 6803
WS:2811 2801 2812
Output power:2048 IC PIXEL
RF touch music RGB controller LT-MUSIC-02
Connection:Common anode
Working voltage:12V - 24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
Bluetooth music RGB controller LT-MUSIC-B1
Connection:Common anode
Working voltage:12V - 24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
IR 24 key music RGB controller LT-MUSIC-01
Connection:Common anode
Working voltage:12V - 24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
IR 24 key magic color controller LT-IRM-17K
Connection:Common anode
Working voltage:5V-24V
IC:6803,1903,2811,2812,16703,6812
Mode:316mode
Output power:2048 IC PIXEL
IR 21 key mini magic color controller LT-IRM-21K
Connection:Common anode
Working voltage:5V-24V
IC:6803,1903,2811,2812,16703,6812
Mode:316mode
Output power:2048 IC PIXEL
IR 21 key magic color controller LT-IRQ-21K
Connection:Common anode
Working voltage:5V-24V
IC:6803,1903,2811,2812,16703,6812
Mode:316mode
Output power:2048 IC PIXEL
2.4G grouping single color controller LT-2.4G-DW1
Connection:Common anode
Working voltage:12V-24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
2.4G grouping RGBW controller LT-2.4G-DB4
Connection:Common anode
Working voltage:12V-24V
Output current:4*4A=16A
Output power:12V<192W,24V<384W
2.4G grouping RGBW controller LT-2.4G-CD4
Connection:Common anode
Working voltage:12V-24V
Output current:4*6A=24A
Output power:12V<288W,24V<576W
RGBW Amplifier (24A) LT-A07
Connection:Common anode
Working voltage:12V - 24V
Output current:4*6A=24A
Output power:12V<288W,24V<576W
Iron sheel RGB Amplifier (30A) LT-M3-T2
Connection:Common anode
Working voltage:12V - 24V
Output current:3*10A=30A
Output power:12V<360W,24V<720W
RGB Amplifier (18A clips) LT-A04
Connection:Common anode
Working voltage:12V - 24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
Mini IR 24 key RGB controller (fireproofing PCB) LT-IR-F1
Connection:Common anode
Working voltage:12V(24V selectable )
Output current:3*2A=6A
Output power:12V<72W,24V<144W
Mini IR 24 key RGB controller (double layer PCB) LT-IR-S1
Connection:Common anode
Working voltage:12V(24V selectable )
Output current:3*2A=6A
Output power:12V<72W,24V<144W
IR 24 key single color controller (double layer PCB) LT-IR-24S
Connection:Common anode
Working voltage:12V(24V selectable )
Output current:1*6A=6A
Output power:12V<72W,24V<144W
2.4G touch RGB controller (blister suit)LT-S-303
Connection:Common anode
Working voltage:12V - 24V
Output current:3*6A=18A
Output power:12V<216W,24V<432W
RF touch 3 zone RGB color controller (blister suit)LT-RFMS-03
Connection:Common anode
Working voltage:12V - 24V
Output current:3*4A=12A
Output power:12V<144W,24V<288W
2.4G touch two color controller (blister suit) LT-S-302
Connection:Common anode
Working voltage:12V - 24V
Output current:2*6A=12A
Output power:12V<144W,24V<288W
Mini RF 17 key RGB controller LT-MRF-02
Connection:Common anode
Working voltage:12V(24V selectable )
Output current:3*2A=6A
Output power:12V<72W,24V<144W
Mini RF 17 key RGB controller with USB connector LT-USB-17
Connection:Common anode
Working voltage:5V(12V selectable )
Output current:3*2A=6A
Output power:5V<30W,12V<60W
Mini RF 17 key RGB controller (new) LT-NEW-01
Connection:Common anode
Working voltage:12V(24V selectable )
Output current:3*2A=6A
Output power:12V<72W,24V<144W
0-10V led dimmer
0-10V LED DIMMER
Connection:Common anode
Working voltage:90-265V
Output current:signal <100ma
Need work with 0-10V led driver
Traic led dimmer
TRAIC LED DIMMER
Input Voltage :90-250VAC
PE383 200w(110v) 400w(220v)
Dimming:Trailing edge dimmer
Need work with traic dimming led driver
